Ford Explorer V facelift (2015-2018) strobes pwr Wiring diagrams

This page contains all the electrical diagrams for the component. strobes pwr, in which he is found in the car Ford Explorer V facelift (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram strobes pwr (1 of 3)

Wiring diagram strobes pwr for Ford Explorer V facelift (2015-2018) (1 of 3)

Get lifetime access to Ford Explorer V facelift (2015-2018)

BATTERY JUNCTION BOX (BJB) BLK/GRY WIRE BLK/VIO WIRE BLU/WHT WIRE BRN WIRE BRN/VIO WIRE FUSE 89 GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT W/ POLICE RUN/START RELAY ILLUM LEFT FRONT AUXILIARY FLASHING LED LEFT FRONT PARK/TURN/ WARN FLASHING LED LEFT REAR LAMP, QUARTER GLASS FLASHING LED LIGHTING/SIREN CONTROL MODULE MEGA FUSE 48 MEGA FUSE 50 NCA WIRE PATTERN POLICE POLICE W/ GRILLE PREPARATION RIGHT FRONT AUXILIARY FLASHING LED RIGHT FRONT PARK/TURN/ WARN FLASHING LED RIGHT REAR LAMP, QUARTER GLASS FLASHING LED SHIELD SIREN SIREN SPEAKER STROBE CONTROL MODULE STROBES PWR SYNCRON VIO WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE VPWR WHT/BRN WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component -> Exterior lamps circuit (3 of 4) -> STROBES PWR

Wiring diagram strobes pwr (2 of 3)

Wiring diagram strobes pwr for Ford Explorer V facelift (2015-2018) (2 of 3)

Get lifetime access to Ford Explorer V facelift (2015-2018)

AJAR BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/VIO WIRE BRN/YEL WIRE CAN (+) COMPUTER DATA LINES SYSTEM DOOR LOCK DOOR UNLOCK FUSE 23 FUSE 89 GRY/ORG WIRE HOT W/ DELAYED ACCY RELAY ENERGIZED HOT W/ POLICE RUN/START RELAY ENERGIZED ILLUM LEFT FRONT DOOR LOCK SWITCH (W/O MEMORY) LIFTGATE LATCH LIGHTING/SIREN CONTROL MODULE (UNDER CENTER OF SECOND ROW SEATS) LOCK MICRO - NCA WIRE NOT AJAR POWER DISTRIBUTION SYSTEM RIGHT FRONT DOOR LOCK SWITCH (W/O MEMORY) SHIELD SIREN SIREN SPEAKER STROBES PWR UNLOCK VIO WIRE VIO/GRY WIRE VIO/ORG WIRE VPWR WHT WIRE WHT/BLU WIRE WHT/BRN WIRE YEL WIRE YEL/VIO WIRE

Go to component -> Forced entry circuit (4 of 5) -> STROBES PWR
