Ford Explorer V facelift (2015-2018) seat select sw Wiring diagram

BATT + BATTERY JUNCTION BOX (BJB) BLK/GRY WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/WHT WIRE BRN/YEL WIRE DEMAND LP/ BATTERY SAVER RELAY ENABLE FOLD FOLD/TAILGATE SW FUSE 1 FUSE 78 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE HOT AT ALL TIMES LATCH NEG LEFT LEFT HALL REC NEG LEFT HALL REC POS LEFT HALL STOW NEG LEFT HALL STOW POS LEFT LATCH POS LEFT LATCH SW LEFT MOT REC NEG LEFT MOT REC POS LEFT MOT STOW NEG LEFT MOT STOW POS LEFT THIRD ROW POWER SEAT LATCH LEFT THIRD ROW POWER SEAT LATCH SWITCH LEFT THIRD ROW POWER-FOLD SEAT MOTOR LEFT THIRD ROW POWER-STOW SEAT MOTOR MEGA FUSE 100 MICRO - MS CAN + NORMAL NORMAL STOW SW POWER FOLD SEAT MODULE (PFSM) RED WIRE RELAY MODULE RETURN LATCH SW RETURN SW RIGHT RIGHT HALL REC POS RIGHT HALL STOW NEG RIGHT HALL STOW POS RIGHT LATCH POS RIGHT LATCH SW RIGHT MOT REC NEG RIGHT MOT REC POS RIGHT MOT STOW NEG RIGHT MOT STOW POS RIGHT THIRD ROW POWER SEAT LATCH RIGHT THIRD ROW POWER SEAT LATCH SWITCH RIGHT THIRD ROW POWER-FOLD SEAT MOTOR RIGHT THIRD ROW POWER-STOW SEAT MOTOR SEAT SELECT SW STOW TAIL THIRD ROW POWER SEAT RELAY THIRD ROW SEAT CONTROL SWITCH VIO WIRE VIO/BRN WIRE VIO/ORG WIRE VIO/WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE
