Ford Explorer V facelift (2015-2018) rear video camera Wiring diagrams
This page contains all the electrical diagrams for the component. rear video camera, in which he is found in the car Ford Explorer V facelift (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear video camera (1 of 4)
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLU/GRY WIRE
BRN/GRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
FRONT VIDEO CAMERA (BEHIND CENTER OF FRONT FASCIA)
FUSE 34
GRN WIRE
GRN/BLU WIRE
GRY WIRE
HOT W/ RUN/START RELAY ENERGIZED
IMAGE PROCESSING MODULE B (IPMB)
LIFTGATE APPLIQUE
LIN 04
NCA WIRE
POWER DISTRIBUTION SYSTEM
REAR VIDEO CAMERA
SHIELD
SHIELD GND
SYNC MODULE (APIM) (CENTER OF DASH)
VIDEO+
VIO/GRY WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> All around vision camera circuit -> REAR VIDEO CAMERA
Wiring diagram rear video camera (2 of 4)
3.5L TURBO, 3.5L TWIN TURBO
3.5L, 3.7L
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
AUXILIARY BLOWER MOTOR RELAY
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLOWER MOTOR RELAY
BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRN/VIO WIRE
CRUISE CONTROL MODULE (C-CM)
FROM POWER POINT RELAY 1 (DIAGRAM 7 OF 8)
FRONT VIDEO CAMERA
FUEL PUMP (FET)
FUSE 30
FUSE 31
FUSE 32
FUSE 33
FUSE 34
GRN/VIO WIRE
GRY WIRE
HEADLAMP CONTROL MODULE (HCM)
IMAGE PROCESSING MODULE B (IPMB)
LEFT HEADLAMP ASSEMBLY
LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L)
LIFTGATE APPLIQUE
MICRO BODY CONTROL MODULE (BCM)
NCA WIRE
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
REAR VIDEO CAMERA
REAR WINDOW DEFROST RELAY
RIGHT HEADLAMP ASSEMBLY
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R)
RUN/ START RELAY
TO BATTERY JUNCTION BOX (BJB) (DIAGRAM 6 OF 8)
TRAILER BATTERY CHARGE RELAY
W/ DYNAMIC LEVELING
WHT/BRN WIRE
YEL/BLU WIRE
Go to component -> Power distribution circuit (8 of 8) -> REAR VIDEO CAMERA
Wiring diagram rear video camera (3 of 4)
AUTO DIMMING INTERIOR MIRROR
BATTERY JUNCTION BOX (BJB)
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/VIO WIRE
FUSE 34
GRN WIRE
GRY WIRE
HOT W/ RUN/START RELAY ENERGIZED
LIFTGATE APPLIQUE
LIN 03
LIN 4
MICRO -
NCA WIRE
REAR VIDEO CAMERA
SHIELD GND
VIDEO+
VIO WIRE
VIO/WHT WIRE
VPWR
W/ BLIND SPOT MONITORING W/O BLIND SPOT MONITORING
WHT WIRE
WHT/GRN WIRE
Go to component -> Rear camera circuit, base -> REAR VIDEO CAMERA
Wiring diagram rear video camera (4 of 4)
4.2 INCH SCREEN
8 INCH SCREEN
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/VIO WIRE
FRONT CONTROL/ DISPLAY INTERFACE MODULE (FCDIM)
FUSE 34
GRN WIRE
HOT W/ RUN/START RELAY ENERGIZED
LIFTGATE APPLIQUE
LIN 03
LIN 4
MICRO -
NCA WIRE
REAR VIDEO CAMERA
SHIELD
SHIELD GND
SYNC MODULE (APIM)
VIDEO+
VIO WIRE
VIO/WHT WIRE
VPWR
W/ BLIND SPOT MONITORING W/O BLIND SPOT MONITORING
WHT WIRE
WHT/GRN WIRE
Go to component -> Rear camera circuit, except base -> REAR VIDEO CAMERA
