Ford Explorer V facelift (2015-2018) not ajar Wiring diagrams

This page contains all the electrical diagrams for the component. not ajar, in which he is found in the car Ford Explorer V facelift (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram not ajar (1 of 2)

Wiring diagram not ajar for Ford Explorer V facelift (2015-2018) (1 of 2)

Get lifetime access to Ford Explorer V facelift (2015-2018)

AJAR BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/VIO WIRE BRN/YEL WIRE CAN (+) COMPUTER DATA LINES SYSTEM DOOR LOCK DOOR UNLOCK FUSE 23 FUSE 89 GRY/ORG WIRE HOT W/ DELAYED ACCY RELAY ENERGIZED HOT W/ POLICE RUN/START RELAY ENERGIZED ILLUM LEFT FRONT DOOR LOCK SWITCH (W/O MEMORY) LIFTGATE LATCH LIGHTING/SIREN CONTROL MODULE (UNDER CENTER OF SECOND ROW SEATS) LOCK MICRO - NCA WIRE NOT AJAR POWER DISTRIBUTION SYSTEM RIGHT FRONT DOOR LOCK SWITCH (W/O MEMORY) SHIELD SIREN SIREN SPEAKER STROBES PWR UNLOCK VIO WIRE VIO/GRY WIRE VIO/ORG WIRE VPWR WHT WIRE WHT/BLU WIRE WHT/BRN WIRE YEL WIRE YEL/VIO WIRE

Go to component -> Forced entry circuit (4 of 5) -> NOT AJAR

Wiring diagram not ajar (2 of 2)

Wiring diagram not ajar for Ford Explorer V facelift (2015-2018) (2 of 2)

Get lifetime access to Ford Explorer V facelift (2015-2018)

Go to component -> Power door locks circuit (4 of 5) -> NOT AJAR

Ford Explorer V facelift (2015-2018) not ajar Wiring diagrams

Wiring diagram not ajar (1 of 2)

List of components:

Wiring diagram not ajar (2 of 2)

List of components:
