Headlights circuit, w/ dynamic leveling for Ford Explorer V facelift 2 (2017-2019)

AIR CONDITIONING SYSTEM AUTOLAMP AUTOLAMP/SUNLOAD SENSOR (TOP CENTER OF DASH) BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/BLU WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DRL LAMPS (FET) DRL LPS FRONT HEADLAMP LEVELING SENSOR (BEHIND LEFT HEADLAMP) FUSE 30 GRN WIRE GRN/BLU WIRE GRY/BLU WIRE GRY/BRN WIRE HEADLAMP CONTROL MODULE (HCM) HIGH BEAM HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED HS 1 CAN + INSTRUMENT PANEL CLUSTER (IPC) LEFT FRONT FOG LAMP LEFT HEADLAMP ASSEMBLY LEVELING MTR PWR LF FOG LAMP (FET) LF HIGH BEAM (FET) LF LOW BEAM (FET) LIN 06 LIN GND LIN LEFT LIN MDM LIN RIGHT LOW BEAM MEGA FUSE 48 MICRO - NCA WIRE PARK BRAKE PARK/TURN GND PARKING BRAKE SWITCH PWR GND REAR HEADLAMP LEVELING SENSOR SENSOR SENSOR GND SHIELD SIGNAL START/RUN TURN LP VIO WIRE VIO/ORG WIRE VIO/RED WIRE W/ FOG LAMPS W/O FOG LAMPS WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/ORG WIRE YEL/VIO WIRE

ADDRESS AUTO AUTOLAMP ON BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BODY CONTROL MODULE (BCM) BRN WIRE CARGO LAMP COMPUTER DATA LINES SYSTEM DIM + DRL LAMPS (FET) DRL LPS EXCEPT POLICE FOG LAMPS ON FOG/ CARGO LAMP GRN/ORG WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE HEAD/PARK HEADLAMP SWITCH HIGH BEAM HOT AT ALL TIMES INPUT LAMPS OFF LAMPS ON LEDS LEFT REAR LAMP ASSEMBLY LEVELING MTR PWR LIN GND LIN MDM LO BEAM LOW BEAM REQ MEGA FUSE 50 MICRO - MULTI- FUNCTION SWITCH NCA WIRE OFF PARK PARK LAMPS ON PARK TURN GND POLICE REAR FOG REAR FOG LAMP/ CARGO LAMP REAR FOG LAMPS REAR FOG LAMPS (FET) RF FOG LAMP (FET) RF HIGH BEAM (FET) RF LOW BEAM (FET) RIGHT FRONT FOG LAMP RIGHT HEADLAMP ASSEMBLY STEERING COLUMN CONTROL MODULE (SCCM) TURN LAMP VIO WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE W/ FOG LAMPS W/O FOG LAMPS W/ REAR FOG LAMPS WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLU WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE
