Ford Explorer V facelift 2 (2017-2019) passive anti-theft transceiver Wiring diagrams
This page contains all the electrical diagrams for the component. passive anti-theft transceiver, in which he is found in the car Ford Explorer V facelift 2 (2017-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passive anti-theft transceiver (1 of 2)
ADJUSTABLE PEDAL SWITCH
ALL TERRAIN CONTROL MODULE (ATCM)
BLK WIRE
BLOWER MOTOR SPEED CONTROL
DATA LINK CONNECTOR (DLC)
EXCEPT POLICE
EXCEPT POLICE W/O INTERIOR UPGRADE PACKAGE
EXTENDED POWER MODULE
FRONT CONSOLE POWER POINT
FRONT POWER OUTLET SOCKET
GATEWAY MODULE
GLOVE COMPARTMENT LAMP
GRN WIRE
GRY WIRE
HEAD-UP DISPLAY (HUD) MODULE
HEADLAMP CONTROL MODULE (HCM)
HEADLAMP SWITCH
HEATED STEERING WHEEL MODULE (HSWM)
HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE
IGNITION SWITCH
IN-VEHICLE TEMPERATURE/ HUMIDITY SENSOR
INSTRUMENT PANEL CLUSTER (IPC)
INSTRUMENT PANEL POWER POINT
PASSIVE ANTI-THEFT TRANSCEIVER
POLICE
REAR FOOTWELL LAMP
REAR HEATING, VENTILATION, AIR CONDITIONING (RHVAC) CONTROL MODULE
REAR POWER POINT CONSOLE
REAR USB POWER OUTLET
RIGHT FRONT FOOTWELL LAMP
STEERING COLUMN CONTROL MODULE (SCCM)
STEERING COLUMN LOCK MODULE
TOP FINISH PANEL LAMP
TRAILER BRAKE CONTROL (TBC) MODULE CONNECTOR
W/ ADAPTIVE CRUISE
W/ DYNAMIC LEVELING
WHT WIRE
Go to component -> Ground distribution circuit (3 of 7) -> PASSIVE ANTI-THEFT TRANSCEIVER
Wiring diagram passive anti-theft transceiver (2 of 2)
3.5L, 3.7L
ANT
BATTERY JUNCTION BOX (BJB)
BLK/WHT WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
ECU DRIVE (PCM WAKE UP) (FET)
GRN/BLU WIRE
GROUND
GRY/VIO WIRE
HALF BRIDGE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
KEYLESS ENTRY CENTER ANTENNA
KEYLESS ENTRY REAR ANTENNA
MEGA FUSE 50
MICRO -
PASSIVE ANTI-THEFT TRANSCEIVER
POWER
POWERTRAIN CONTROL MODULE (PCM)
PROTECT 1 ANTENNA HI (HB)
PROTECT 1 ANTENNA LO (HB)
PROTECT 2 ANTENNA HI (HB)
PROTECT 2 ANTENNA LO (HB)
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Passive anti-theft circuit -> PASSIVE ANTI-THEFT TRANSCEIVER
