Ford Explorer V facelift 2 (2017-2019) passenger scuff plate Wiring diagrams
This page contains all the electrical diagrams for the component. passenger scuff plate, in which he is found in the car Ford Explorer V facelift 2 (2017-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger scuff plate (1 of 2)
AMBIENT LTG (FET)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (BCM)
CARGO LAMP (THIRD ROW)
DRIVER SCUFF PLATE
FUSE
GLOVE COMPARTMENT LAMP
GND BACK LIGHTING PWR
GRN/RED WIRE
GRY/VIO WIRE
HOMELINK
HOT AT ALL TIMES
LEFT FRONT DOOR LED
LEFT FRONT FOOTWELL LAMP
LEFT SIDE RAIL LAMP
LEFT VANITY MIRROR LAMP
LIN BUS
MEGA FUSE 100
MEGA FUSE 48
MEGA FUSE 50
MICRO -
MODULE
NCA WIRE
OFF
PASSENGER SCUFF PLATE
PWR
REAR FOOTWELL LAMP
RED WIRE
RIGHT FRONT DOOR LED
RIGHT FRONT FOOTWELL LAMP
RIGHT SIDE RAIL LAMP
RIGHT VANITY MIRROR LAMP
TOP FINISH PANEL LAMP
VIO WIRE
VIO/GRY WIRE
VIO/RED WIRE
W/ MOONROOF
WHT/VIO WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> PASSENGER SCUFF PLATE
Wiring diagram passenger scuff plate (2 of 2)
