Power seats circuit, 6-way passenger seat for Ford Explorer V (2010-2015)
Power seats circuit, 6-way passenger seat
AFT FORE/
BATTERY
BLK WIRE
BLU WIRE
DOWN
FRONT HEIGHT
FUSE JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HORIZONTAL
HOT AT ALL TIMES
PASSENGER SEAT FRONT HEIGHT MOTOR
PASSENGER SEAT HORIZONTAL MOTOR
PASSENGER SEAT REAR HEIGHT MOTOR
PASSENGER SIDE FRONT SEAT CONTROL SWITCH
REAR HEIGHT
RED WIRE
VIO WIRE
WHT WIRE
YEL WIRE
