Adjustable pedal circuit for Ford Explorer V (2010-2015)
Adjustable pedal circuit
14 15 1 14 HS CAN+ HS CAN-
5 4 PWR GND ADJ PDL MTR (FWD)
ADJUSTABLE PEDAL MOTOR (UNDER LEFT SIDE OF DASH)
BLK/BLU WIRE
COM MTR PDL/COL
COMPUTER DATA LINES SYSTEM
EXCEPT POLICE
HOT AT ALL TIMES BODY CONTROL FUSE MODULE (LEFT END OF DASH)
PEDAL ADJUST SWITCH
POLICE
STEERING COLUMN CONTROL MODULE (TOP OF STEERING COLUMN)
VBATT
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
