Power mirrors circuit for Ford Explorer V (2010-2015)
Power mirrors circuit
BASE, POLICE
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
BRN/GRN WIRE
DEFOGGER SYSTEM
DOWN UP
DRIV L/R
DRIV U/D
DRIVER SIDE EXTERIOR REAR VIEW MIRROR
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE 32
FUSE 48
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/ORG WIRE
HOT W/ ACCESSORY DELAY RELAY ENERGIZED
MASTER WINDOW CONTROL SWITCH
PASS L/R
PASS U/D
PASSENGER SIDE EXTERIOR REAR VIEW MIRROR
PUDDLE
PWR
RETURN
RIGHT LEFT
TURN
VIO WIRE
WHT WIRE
WHT/BRN WIRE
XLT, SPORT
XLT, SPORT BASE, POLICE
YEL/GRY WIRE
