Passive anti-theft circuit, without intelligent access for Ford Explorer V (2010-2015)
Passive anti-theft circuit, without intelligent access
1 2 3 4 POWER GROUND TX RX
12 13 HS CAN + HS CAN -
3.5L 2.0L TURBO
BLK/BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
EPATS RX
EPATS TX
FUSE 18
HOT AT ALL TIMES
HS CAN+
INSTRUMENT PANEL CLUSTER (IPC)
MICRO -
PASSIVE ANTI-THEFT TRANSCEIVER (LEFT SIDE OF DASH)
PCM WAKEUP (FET)
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
