Ford Explorer V (2010-2015) right second row seat control switch Wiring diagram
This page shows the only wiring diagram for the component.right second row seat control switch, which is found in the car Ford Explorer V (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right second row seat control switch (1 of 1)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BATTERY SAVER RELAY
BLK WIRE
BLK/GRN WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
FUSE 61
GRN/BRN WIRE
GRN/RED WIRE
GRY/BRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE 4
LEFT SECOND ROW POWER RELEASE SEAT MOTOR
LEFT SECOND ROW SEAT CONTROL SWITCH
MICRO -
RIGHT SECOND ROW POWER RELEASE SEAT MOTOR
RIGHT SECOND ROW SEAT CONTROL SWITCH
YEL/GRN WIRE
