Ford Explorer V (2010-2015) right license plate lamp rear window wiper motor Wiring diagram
This page shows the only wiring diagram for the component.right license plate lamp rear window wiper motor, which is found in the car Ford Explorer V (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right license plate lamp rear window wiper motor (1 of 1)
4 PIN TRAILER TOW CONNECTOR
7 PIN TRAILER TOW CONNECTOR
ASSEMBLY, NEAR BREAKOUT TO LEFT FRONT SEAT CUSHION HEATER MAT)
AUXILIARY BLOWER MOTOR CONTROL
BLK WIRE
BLU WIRE
DRIVER SIDE FRONT SEAT CONTROL SWITCH
EARLY PRODUCTION
EXCEPT POLICE W/O REAR PARKING AID
GRN WIRE
GRY WIRE
HIGH MOUNTED STOP LAMP
LATE PRODUCTION
LEFT LICENSE PLATE LAMP
LEFT REAR LAMP ASSEMBLY
LIFTGATE LIFTGATE REAR LATCH/ CONTROL UNLATCH ASSEMBLY SWITCH
NCA WIRE
PARKING AID MODULE (PAM)
POLICE W/O REAR PARKING AID
REAR WINDOW DEFROST GRID
RIGHT LICENSE PLATE LAMP REAR WINDOW WIPER MOTOR
RIGHT REAR LAMP ASSEMBLY
SAFETY BELT BUCKLE SWITCH
W/ 10-WAY POWER SEAT
W/ POWER LIFTGATE
WHT WIRE
Go to component -> Ground distribution circuit (4 of 6) -> RIGHT LICENSE PLATE LAMP REAR WINDOW WIPER MOTOR
