Ford Explorer V (2010-2015) point 1 memory Wiring diagram
This page shows the only wiring diagram for the component.point 1 memory, which is found in the car Ford Explorer V (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram point 1 memory (1 of 1)
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
AUXILIARY
BATTERY
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BATTERY REAR WINDOW CHARGE BLOWER TRAILER TOW DEFROST MOTOR RELAY RELAY RELAY
BLK/ GRY WIRE
BLK/GRY WIRE
BLU RED/ WIRE
BLU/RED WIRE
BRAKE LEFT PEDAL HEADLAMP POSITION ASSEMBLY (BPP) (W/ HID) SWITCH
BRN/RED WIRE
DRIVER SIDE FRONT SEAT CONTROL SWITCH
EXCEPT POLICE POLICE
FRONT CONSOLE POWER POINT
FUSE
FUSE 18 FUSE 19 FUSE 4 FUSE
FUSE 20
FUSE 22
FUSE 23
FUSE 26 FUSE 39
FUSE 27 FUSE
FUSE 56
FUSE 58 FUSE 17 FUSE
FUSE 7
FUSE 8
FUSE 9
FUSE FUSE
FUSE FUSE 6
FUSE FUSE FUSE
FUSIBLE LINK A (10 GA-
FUSIBLE LINK B (10 GA-
GENERATOR
GRN RED/ WIRE
GRN/RED WIRE
GRY BLK/ WIRE
GRY WIRE
GRY/RED WIRE
HIGH CURRENT BATTERY JUNCTION FUSE BOX (BJB) (LEFT REAR OF ENGINE COMPT)
INSTRUMENT PANEL POWER
INSTRUMENT PANEL POWER POINT
INSTRUMENT PANEL POWER POINT 2
LIFTGATE/ TRUNK MODULE (LTM)
LOW FAN HIGH FAN COOLING COOLING (LFC) (HFC) RELAY RELAY
POINT 1 MEMORY
POWER STEERING CONTROL MODULE (PSCM)
REAR CONSOLE POWER POINT
RED BRN/ WIRE
RED GRN/ WIRE
RED WIRE
RED/ VIO WIRE
RIGHT REAR POWER POINT (POLICE)
ROOF OPENING PANEL MODULE
STARTER MOTOR
TO BODY CONTROL MODULE (BCM) (DIAGRAM 3 OF 5)
TO DC/AC INVERTER MODULE (DIAGRAM 4 OF 5)
TO FUSE 40 (DIAGRAM 2 OF 5)
TRAILER BRAKE CONTROL (TBC) MODULE CONNECTOR
TRANSMISSION CNTROL MODULE (TCM) (2.0L TURBO)
VIO RED/ WIRE
VIO/RED WIRE
W/ 10-WAY POWER SEAT
W/ 6 WAY POWER SEAT
W/ CONSOLE W/O CONSOLE
W/O W/ MEMORY
WHT RED/ WIRE
WHT/RED WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 5) -> POINT 1 MEMORY
