Ford Explorer V (2010-2015) (passenger's seat wiring assembly, near breakout Wiring diagram
This page shows the only wiring diagram for the component.(passenger's seat wiring assembly, near breakout, which is found in the car Ford Explorer V (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (passenger's seat wiring assembly, near breakout (1 of 1)
AUTO DIMMING INTERIOR MIRROR
BASE, POLICE SPORT, XLT, LIMITED
BLK WIRE
BODY CONTROL MODULE (BCM)
COLUMN SHIFTER
DRIVER SEAT MODULE (DSM)
DRIVER SIDE DOOR LOCK CONTROL SWITCH
DRIVER SIDE EXTERIOR REAR VIEW MIRROR
FLOOR SHIFTER
GRN WIRE
GRY WIRE
KEYLESS ENTRY KEYPAD
LEFT FRONT DOOR LATCH
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR DOOR LATCH
LEFT REAR WINDOW CONTROL SWITCH
MASTER WINDOW CONTROL SWITCH
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
PARKING BRAKE SWITCH
PASSENGER SAFETY BELT BUCKLE
PASSENGER SEAT POSITION SENSOR
RIGHT LEFT VANITY VANITY MIRROR MIRROR LAMP LAMP
ROOF OPENING PANEL MODULE
SAFETY BELT BUCKLE SWITCH
SPORT, XLT, LIMITED
W/ BLIND SPOT
W/ MEMORY
W/O MEMORY
Go to component -> Ground distribution circuit (3 of 6) -> (PASSENGER'S SEAT WIRING ASSEMBLY, NEAR BREAKOUT
