Ford Explorer V (2010-2015) left front park/turn/ warn led assembly Wiring diagrams
This page contains all the electrical diagrams for the component. left front park/turn/ warn led assembly, in which he is found in the car Ford Explorer V (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left front park/turn/ warn led assembly wiring diagram (1 of 2)
1 2 3 4 5 6 PWR PATTERN PATTERN GND STROBES PWR PATTERN
1 2 3 4 VPWR PATTERN SYNCRON GND
1 2 PATTERN PATTERN
3 4 SYNCRON GND
4 3 2 1 GND SYNCRON PATTERN VPWR
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU/WHT WIRE
BRN WIRE
BRN/VIO WIRE
FUSE
FUSE 81
FUSE 93
GND SYNCRON PATTERN VPWR
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUM
ILLUMINATION CIRCUIT
LEFT FRONT CORNER FLASHING LED
LEFT FRONT PARK/TURN/ WARN LED ASSEMBLY
LEFT TAILLAMP FLASHING LED
LIGHTING/SIREN CONTROL MODULE
NCA WIRE
ORG/ WIRE
PATTERN
POLICE RUN/ START RELAY
PWR STROBES PWR STROBES PWR
RED WIRE
RIGHT FRONT CORNER FLASHING LED
RIGHT FRONT PARK/TURN/ WARN LED ASSEMBLY
RIGHT TAILLAMP FLASHING LED
SHIELD
SIREN + SIREN -
SIREN SPEAKER (LEFT FRONT OF ENG COMPT)
STROBE CONTROL MODULE (BASE OF LEFT "D" PILLAR)
STROBES PWR
SYNCRON GND
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VPWR
W/ GRILLE PREPARATION
W/O GRILLE PREPARATION
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, police (2 of 3) -> LEFT FRONT PARK/TURN/ WARN LED ASSEMBLY
left front park/turn/ warn led assembly wiring diagram (2 of 2)
