Ford Explorer V (2010-2015) fuse 18 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse 18, in which he is found in the car Ford Explorer V (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse 18 (1 of 3)
1 2 3 4 POWER GROUND TX RX
12 13 HS CAN + HS CAN -
3.5L 2.0L TURBO
BLK/BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
EPATS RX
EPATS TX
FUSE 18
HOT AT ALL TIMES
HS CAN+
INSTRUMENT PANEL CLUSTER (IPC)
MICRO -
PASSIVE ANTI-THEFT TRANSCEIVER (LEFT SIDE OF DASH)
PCM WAKEUP (FET)
VIO WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Passive anti-theft circuit, without intelligent access -> FUSE 18
Wiring diagram fuse 18 (2 of 3)
