Ford Explorer V (2010-2015) flp tcbp frp iat cact ect wvs wiring diagram
This page shows the only wiring diagram for the component.flp tcbp frp iat cact ect wvs, which is found in the car Ford Explorer V (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
flp tcbp frp iat cact ect wvs wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
CHT
CKP SIGRTN
COOLING FANS SYSTEM
ETCRTN FTP
FLP TCBP FRP IAT CACT ECT WVS
FUEL INJECTION PUMP (RIGHT REAR OF ENGINE)
GRN WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/YEL WIRE
INTAKE AIR TEMPERATURE (IAT) SENSOR (LEFT FRONT OF ENGINE COMPT)
KNOCK
KNOCK SENSOR 1
LFC
LIN
OF ENGINE COMPT)
OIL PRESSURE SWITCH (LEFT SIDE OF ENGINE BLOCK)
OPS
POWERTRAIN CONTROL MODULE (PCM) (CENTER REAR
SIGRTN
TACM+
TCBY
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VREF
VREF ETCREF
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (6 of 6) -> FLP TCBP FRP IAT CACT ECT WVS
