Ford Explorer V (2010-2015) autolamp ms sens in can+ Wiring diagram
This page shows the only wiring diagram for the component.autolamp ms sens in can+, which is found in the car Ford Explorer V (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram autolamp ms sens in can+ (1 of 1)
2.0L TURBO
3.5L 2.0L 3.5L TURBO TURBO
35 51 17 31 51 52 AAT ACPT
59 58 HS CAN+ HS CAN-
A/C CLUTCH RELAY
A/C COMPRESSOR CLUTCH FIELD COIL (LOWER LEFT FRONT
A/C PRESSURE TRANSDUCER (RIGHT FRONT OF ENGINE COMPT)
ACCR
AMBIENT AIR TEMPERATURE (AAT) SENSOR (BEHIND LEFT SIDE OF GRILLE)
AUTOLAMP MS SENS IN CAN+
BATTERY JUNCTION BOX (BJB)
BLK/GRN WIRE
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM) (LEFT END OF DASH)
BRN WIRE
CHT
COMPUTER DATA LINES SYSTEM
ECT
EVDC
EXCEPT 2.0L TURBO
FUSE
FUSE 62
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HFC
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
LFC
MICRO -
MS CAN +
OF ENGINE)
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM) (CENTER REAR OF ENGINE COMPT)
RED WIRE
SIGRTN
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VREF
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit (3 of 4) -> AUTOLAMP MS SENS IN CAN+
