Ford Explorer V (2010-2015) 18 21 bpp strt/stp 1 Wiring diagrams
This page contains all the electrical diagrams for the component. 18 21 bpp strt/stp 1, in which he is found in the car Ford Explorer V (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 18 21 bpp strt/stp 1 (1 of 2)
18 21 BPP STRT/STP 1
2.0L TURBO
2.0L TURBO, 3.5L TURBO, 3.5L EXCEPT POLICE
3.5L POLICE
36 26 27 30 17 32 41 39 40 38 TSS/OSS/TR GND TR 1 TR 2 TR 3 TR 4
7 6 5 4 8 TR 4 TR 3 TR 2 TR 1 TR GND
BATTERY JUNCTION
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
BOX (LEFT SIDE OF ENGINE COMPT)
BRAKE PEDAL POSITION (BPP) SWITCH
BRAKE SHIFT INTERLOCK (LEFT SIDE OF DASH)
BREAKOUT TO
BRN WIRE
BRN/BLU WIRE
BSI (FET)
COMPUTER DATA LINES SYSTEM
FUSE 18
FUSE 28
FUSE 31
FUSE 59
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HS CAN+
IGNITION SWITCH
IN PARK
INSTRUMENT PANEL CLUSTER (IPC)
KEY IN BPP
KEY IN IGNITION
LOCK
MICRO -
MS CAN +
NCA WIRE
ORG/ WIRE
PARK DETECT
RED WIRE
SHIFT LOCK SOLENOID
SRT/STP 1
STARTING/ CHARGING SYSTEM
TRAILER BRAKE CONTROL (TBC) MODULE CONNECTOR
TRANSMISSION
TRANSMISSION (3.5L, 3.5L TURBO)
TRANSMISSION CONTROL MODULE (2.0L TURBO) (LEFT SIDE OF ENGINE COMPT)
TRANSMISSIONS SYSTEM
TRS
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ INTELLIGENT ACCESS
W/O INTELLIGENT ACCESS
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Shift interlock circuit, with column shift -> 18 21 BPP STRT/STP 1
Wiring diagram 18 21 bpp strt/stp 1 (2 of 2)
18 21 BPP STRT/STP 1
2.0L TURBO
2.0L TURBO, 3.5L TURBO, 3.5L EXCEPT POLICE
3.5L POLICE
36 26 27 30 17 32 41 39 40 38 TSS/OSS/TR GND TR 1 TR 2 TR 3 TR 4
7 6 5 4 8 TR 4 TR 3 TR 2 TR 1 TR GND
ASSEMBLY, NEAR BREAKOUT TO AUTOLAMP/SUNLOAD SENSOR) (W/ INTELLIGENT ACCESS)
BATTERY JUNCTION
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
BOX (LEFT SIDE OF ENGINE COMPT)
BRAKE PEDAL POSITION (BPP) SWITCH
BRAKE SHIFT INTERLOCK (UNDER CENTER CONSOLE)
BREAKOUT TO
BRN WIRE
BRN/BLU WIRE
BSI (FET)
COMPUTER DATA LINES SYSTEM
FUSE 18
FUSE 28
FUSE 31
FUSE 59
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HS CAN+
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
KEY IN BPP
KEY IN IGNITION
LOCK
MICRO -
MS CAN +
NCA WIRE
ORG/ WIRE
PARK DETECT
RED WIRE
SHIFT LOCK SOLENOID IN PARK
SRT/STP 1
START/STOP 1 (ACTIVE HIGH)
START/STOP SWITCH
STARTING/ CHARGING SYSTEM
STT-U STT-D GRADE SIGRTN ASSIST (W/O TRAILER TOW)
TRAILER BRAKE CONTROL (TBC) MODULE CONNECTOR
TRANSMISSION
TRANSMISSION (3.5L, 3.5L TURBO)
TRANSMISSION CONTROL MODULE (2.0L TURBO) (LEFT SIDE OF ENGINE COMPT)
TRANSMISSIONS SYSTEM
TRS
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/ INTELLIGENT ACCESS
W/O INTELLIGENT ACCESS
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Shift interlock circuit, with floor shift -> 18 21 BPP STRT/STP 1
