Ford Explorer V (2010-2015) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 batt antenna pwr Wiring diagrams
This page contains all the electrical diagrams for the component. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 batt antenna pwr, in which he is found in the car Ford Explorer V (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 batt antenna pwr (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 BATT ANTENNA PWR
21 22 23 24 LR SPKR + LF SPKR + RF SPKR + RR SPKR +
6 5 4 3 2 1 GND
ACCESSORY PROTOCOL INTERFACE MODULE
ALERT -
AUDIO CONTROL MODULE (ACM)
BLK/BLU WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COAXIAL CABLE COAXIAL CABLE
COAXIAL CABLE COAXIAL CABLE SDARS AM/FM
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM (UNDER RIGHT FRONT OF CENTER CONSOLE)
GLOBAL POSITIONING SYSTEM MODULE
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES BODY CONTROL MODULE (LEFT END OF DASH) FUSE 29
INSTRUMENT PANEL SPEAKER
IP SPKR +
LEFT FRONT SPEAKER
LEFT FRONT TWEETER
LEFT REAR SPEAKER
MS CAN - MS CAN + VBATT
NCA WIRE
POLICE
SDL H
SDL L
STARTING/ CHARGING SYSTEM
STATE SOLID
STEREO L- STEREO R-
VIO WIRE
VIO/GRY WIRE
W/ SATELLITE RADIO
W/ SYNC GEN 1 W/ SYNC GEN 2
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
Go to component -> Navigation circuit, without sony (1 of 2) -> 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 BATT ANTENNA PWR
Wiring diagram 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 batt antenna pwr (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 BATT ANTENNA PWR
21 22 23 24 LR SPKR + LF SPKR + RF SPKR + RR SPKR +
6 5 4 3 2 1 GND
ACCESSORY PROTOCOL INTERFACE MODULE
ALERT -
AUDIO CONTROL MODULE (ACM)
BLK/BLU WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COAXIAL CABLE COAXIAL CABLE
COAXIAL CABLE COAXIAL CABLE SDARS AM/FM
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM (UNDER RIGHT FRONT OF CENTER CONSOLE)
GLOBAL POSITIONING SYSTEM MODULE
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES BODY CONTROL MODULE (LEFT END OF DASH) FUSE 29
INSTRUMENT PANEL SPEAKER
IP SPKR +
LEFT FRONT SPEAKER
LEFT FRONT TWEETER
LEFT REAR SPEAKER
MS CAN - MS CAN + VBATT
NCA WIRE
POLICE
SDL H
SDL L
STARTING/ CHARGING SYSTEM
STATE SOLID
STEREO L- STEREO R-
VIO WIRE
VIO/GRY WIRE
W/ SATELLITE RADIO
W/ SYNC GEN 1 W/ SYNC GEN 2
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
Go to component -> Premium radio circuit (1 of 2) -> 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 BATT ANTENNA PWR
