Car Wiring Diagrams for Wiper/washer circuit for Ford Explorer IV (2005-2010)

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLK/VIO WIRE BLU WIRE BRN WIRE ELECTRONICS ENGINE COMPT) FRONT WASH SWITCH FRONT WASHER RELAY FRONT WIPER RELAY FRONT WIPER SWITCH FUSE 20 GRN WIRE GRY WIRE HAT HIGH/LOW SPEED RELAY HOT AT ALL TIMES HOT AT ALL TIMES FUSE 24 HOT IN RUN OR ACC FUSE 10 INSTRUMENT CLUSTER ORG/ WIRE PARK RED WIRE RUN WIRE RUN/PARK RELAY SENSE SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) VIO WIRE VIO/RED WIRE WASH LEVEL WASHER FLUID LEVEL SWITCH (RIGHT FRONT CORNER OF ENGINE COMPT) WASHER PUMP MOTOR (ON WASHER RESERVOIR TANK) WHT WIRE WINDSHIELD WIPER MOTOR (AT LEFT REAR OF YEL WIRE
