# Courtesy lamps circuit

# Courtesy lamps circuit

Interior lights — Courtesy lamps circuit — Courtesy lamps circuit. Ford Explorer IV (2005-2010)
Components on the diagram

    # Courtesy lamps circuit (1 of 2)

    Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (1 of 2). Ford Explorer IV (2005-2010)
    Components on the diagram

      # Courtesy lamps circuit (2 of 2)

      Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (2 of 2). Ford Explorer IV (2005-2010)
      Components on the diagram
