4.0l, computer data lines circuit for Ford Explorer IV (2005-2010)

11 12 MS CAN + MS CAN - 3 11 MS CAN + MS CAN - 4 8 7 5 MS CAN + HS CAN - HS CAN + MS CAN - 9 18 HS CAN - HS CAN + ABS TEST CONNECTOR (LEFT SIDE OF ENGINE COMPT) ACCESSORY PROTOCOL INTERFACE MODULE (APIM) (LATE PRODUCTION) ANTI-LOCK BRAKE SYSTEM (ABS) MODULE (LEFT FRONT OF ENGINE COMPT) AUDIO CONTROL MODULE (ACM) BLK/WHT WIRE BLU WIRE DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH) FEPS FUSE 4 GRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/ORG WIRE HOT AT ALL TIMES HS CAN+ INSTRUMENT CLUSTER MODULE MS CAN + OCCUPANT CLASSIFICATION SYSTEM MODULE(OCSM) (UNDER FRONT PASSENGER'S SEAT) ORG/ WIRE PARKING AID MODULE (PAM) (AT RIGHT "D" PILLAR) POWER RUNNING BOARD (PRB) MODULE (ABOVE RIGHT WHEELWELL) POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE) REAR ENTERTAINMENT MODULE (RETM) RED WIRE RESTRAINTS CONTROL MODULE (RCM) (BELOW CENTER FLOOR CONSOLE) SATELLITE DIGITAL AUDIO RECEIVER SYSTEM (SDARS) MODULE (BEHIND RIGHT KICK PANEL) SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) VIO WIRE VIO/ORG WIRE WHT WIRE WHT/BLU WIRE
