Passive anti-theft circuit for Ford Explorer IV (2005-2010)
Passive anti-theft circuit
ANTI-THEFT
AUTOLAMP/ SUNLOAD SENSOR (BEHIND GLOVE BOX)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
EPATS GND
EPATS RX
EPATS TX
FUSE 24
HOT AT ALL TIMES
HS CAN+
IGNITION SWITCH
INSTRUMENT CLUSTER (IC)
OFF
ORG/ WIRE
PASSIVE ANTI-THEFT TRANSCEIVER (ON STEERING COLUMN)
RED WIRE
RF GND
RF PWR
RUN WIRE
RUN/ST
RX SIG
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
TX SIG
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLU WIRE
YEL/ORG WIRE
