Ford Explorer IV (2005-2010) wash level Wiring diagrams
This page contains all the electrical diagrams for the component. wash level, in which he is found in the car Ford Explorer IV (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
wash level wiring diagram (1 of 2)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
ELECTRONICS
FRONT WASHER RELAY
FRONT WIPER RELAY
FRONT WIPER SWITCH
FUSE 20
GRN WIRE
GRY WIRE
HAT
HIGH/LOW SPEED RELAY
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE 24
HOT IN RUN OR ACC FUSE 10
INSTRUMENT CLUSTER
ORG/ WIRE
PARK
REAR WASHER RELAY
REAR WIPER MODULE (CENTER OF LIFTGATE)
RED WIRE
RUN WIRE
RUN/PARK RELAY
SENSE
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
TWO-WAY WASHER PUMP MOTOR (RIGHT FRONT CORNER OF ENGINE COMPT)
VIO WIRE
VIO/RED WIRE
WASH LEVEL
WASHER FLUID LEVEL SWITCH (RIGHT FRONT CORNER OF ENGINE COMPT)
WASHER SWITCH
WHT WIRE
WINDSHIELD WIPER MOTOR (AT LEFT REAR OF ENGINE COMPT)
YEL WIRE
Go to component -> Front wiper/washer circuit -> WASH LEVEL
