Ford Explorer IV (2005-2010) shift interlock system cruise control system Wiring diagrams

This page contains all the electrical diagrams for the component. shift interlock system cruise control system, in which he is found in the car Ford Explorer IV (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram shift interlock system cruise control system (1 of 2)

Wiring diagram shift interlock system cruise control system for Ford Explorer IV (2005-2010)

Get access

ACCELERATOR PEDAL POSITION SENSOR (UNDER LEFT SIDE OF DASH) ACPT SCCS AIR CONDITIONING SYSTEM BATTERY JUNCTION BOX (BJB) BLK/YEL WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BPS CSGND HS CAN+ FPC VAPVNT ACCR ACCS BRN/GRN WIRE BRN/WHT WIRE CRUISE CONTROL SYSTEM DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH) DEACTIVATOR SWITCH (ON BRAKE PEDAL SUPPORT) FEPS KAPWR ISP-R GROUND GROUND GROUND GROUND FPM ILC HS CAN- FTPREF SIGRTNC FUEL PUMP DIODE FUEL TANK PRESSURE (FTP) SENSOR (UNDER RIGHT SIDE OF VEHICLE) FUSE 24 FUSE 9 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN START OR RUN OD CANCEL SCCS RTN POWER STEERING PRESSURE SWITCH (TOP LEFT FRONT OF ENGINE) POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE ENGINE) PSPSW RED/WHT WIRE SHIFT INTERLOCK SYSTEM CRUISE CONTROL SYSTEM SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE SNS OF DASH) SMR/START STARTING/CHARGING SYSTEM STARTING/CHARGING SYSTEM ANTI-LOCK BRAKES SYSTEM VIO/GRN WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE VPWR VPWR RLY CTRL SMCS WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/VIO WIRE WIPER/WASHER SYSTEM STARTING/CHARGING SYSTEM YEL WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component: -> Wiring diagram engine performance 4.0l (1 of 5) -> SHIFT INTERLOCK SYSTEM CRUISE CONTROL SYSTEM

Wiring diagram shift interlock system cruise control system (2 of 2)

Wiring diagram shift interlock system cruise control system for Ford Explorer IV (2005-2010)

Get access

ACCELERATOR PEDAL POSITION SENSOR (UNDER LEFT SIDE OF DASH) ACPT SCCS AIR CONDITIONING SYSTEM BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT BLK/YEL WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BPS CSGND HS CAN + FPC VAPNT ACCR BRN/GRN WIRE BRN/WHT WIRE CRUISE CONTROL SYSTEM DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH) 14 13 DEACTIVATOR SWITCH (ON BRAKE PEDAL SUPPORT) FENDER APRON) FEPS KAPWR ISP-R GROUND GROUND GROUND GROUND FPM ILC HS CAN- FTPREF SIGRTNC FUEL TANK PRESSURE (FTP) SENSOR (UNDER RIGHT SIDE OF VEHICLE) FUSE 24 FUSE 9 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN START OR RUN OD CANCEL SCCS RTN POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE) RED/WHT WIRE RLY CTRL SMCS SHIFT INTERLOCK SYSTEM CRUISE CONTROL SYSTEM SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) SMR/START SNS FUEL PUMP DIODE STARTING/CHARGING SYSTEM STARTING/CHARGING SYSTEM ANTI-LOCK BRAKES SYSTEM VIO/GRN WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/VIO WIRE WIPER/WASHER SYSTEM STARTING/CHARGING SYSTEM YEL WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component: -> Wiring diagram engine performance 4.6l (1 of 5) -> SHIFT INTERLOCK SYSTEM CRUISE CONTROL SYSTEM
