Ford Explorer IV (2005-2010) left rear turn/ stop Wiring diagrams

This page contains all the electrical diagrams for the component. left rear turn/ stop, in which he is found in the car Ford Explorer IV (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram left rear turn/ stop (1 of 2)

Wiring diagram left rear turn/ stop for Ford Explorer IV (2005-2010)

Get access

1. AUTO 2. OFF 3. PARK 4. LOW 1. FULL LEFT 2. LANE CHANGE 3. NEUTRAL 4. LANE CHANGE 5. FULL RIGHT BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL) BRN WIRE CARGO LAMP ASSEMBLY CONTROL FUSE 22 FUSE 26 FUSE 7 GRN WIRE GRY WIRE HAZARD HOT AT ALL TIMES HSD LEFT FRONT PARK/ TURN LAMP LEFT FRONT SIDE LAMP LEFT FRONT TURN LEFT LICENSE PLATE LAMP LEFT REAR PARK/ STOP/ TURN LAMP RIGHT LICENSE PLATE LAMP LEFT REAR TURN/ STOP MAIN LIGHT SWITCH MULTI- FUNCTION SWITCH NCA WIRE ORG/ WIRE PARK LAMP RELAY RED WIRE REST ON/ OFF RIGHT FRONT PARK/ TURN LAMP RIGHT FRONT SIDE LAMP RIGHT FRONT TURN RIGHT REAR PARK/ STOP/ TURN LAMP RIGHT REAR TURN/ STOP SENSE SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) STOP CARGO TURN SIGNAL VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Exterior lamps circuit -> LEFT REAR TURN/ STOP

Wiring diagram left rear turn/ stop (2 of 2)

Wiring diagram left rear turn/ stop for Ford Explorer IV (2005-2010)

Get access

AUTOLAMP/ SUNLOAD SENSOR BAT SAVER BLU WIRE BRN WIRE CONTROL DRIVER SIDE EXTERIOR REAR VIEW MIRROR FROM FUSE 2 BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 6) FROM FUSE 23 SMART JUNCTION BOX (SJB) (DIAGRAM 3 OF 6) FRONT INTERIOR/ FUSE 22 TO HSD SMART JUNCTION BOX (SJB) (DIAGRAM 5 OF 6) FUSE 23 FUSE 24 FUSE 27 FUSE 28 GLOVE BOX LAMP) GRN WIRE GRY WIRE HAT HAT HAT HORN RELAY HSD INTERIOR LAMPS HSD LEFT FRONT TURN HVAC CLIMATE MODULE CONTROL (DATC) ASSEMBLY (MANUAL A/C) INSTRUMENT CLUSTER (IC) LEFT FRONT PARK/ TURN LAMP LEFT REAR PARK/STOP TURN LAMP LEFT REAR TURN/ STOP LEFT VANITY MIRROR LAMP MAP LAMP ASSEMBLY NCA WIRE PARK LAMP RELAY PASSENGER CARGO SIDE LAMP EXTERIOR ASSEMBLY REAR VIEW MIRROR PUDDLE LAMP RELAY REAR INTERIOR LAMP RED WIRE RIGHT VANITY MIRROR LAMP SIDE OF DASH) SMART JUNCTION BOX (SJB) SMART JUNCTION BOX (SJB) (BEHIND LEFT TO FUSE 28 SMART JUNCTION BOX (SJB) (DIAGRAM 3 OF 6) TO HSD SMART JUNCTION BOX (SJB) (DIAGRAM 4 OF 6) TRICOLOR STOP VIO WIRE W/ MOON- ROOF W/O (IN MOON- INTERIOR LIGHT ROOF FEED HARNESS, NEAR BREAKOUT TO FRONT OF ROOF) W/O MOON- ROOF YEL WIRE

Go to component: -> Power distribution circuit (3 of 6) -> LEFT REAR TURN/ STOP
