Ford Explorer IV (2005-2010) (in seat control feed harness, Wiring diagram
This page shows the only wiring diagram for the component.(in seat control feed harness,, which is found in the car Ford Explorer IV (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (in seat control feed harness, (1 of 1)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BLU WIRE
BRN WIRE
FUSE 12
FUSE 5
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT THIRD ROW FOLDING SEAT MOTOR (BEHIND LEFT SIDE OF THIRD ROW SEAT)
LEFT THIRD ROW FOLDING SEAT RELAY (LEFT REAR CORNER OF VEHICLE)
LEFT THIRD ROW FOLDING SEAT SWITCH
LSD
ORG/ WIRE
RED WIRE
RIGHT THIRD ROW FOLDING SEAT MOTOR (RIGHT REAR OF VEHICLE INTERIOR)
RIGHT THIRD ROW FOLDING SEAT RELAY
RIGHT THIRD ROW FOLDING SEAT SWITCH
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Third row folding seat circuit -> (IN SEAT CONTROL FEED HARNESS,
