Ford Explorer IV (2005-2010) hot at all times Wiring diagrams

This page contains all the electrical diagrams for the component. hot at all times, in which he is found in the car Ford Explorer IV (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram hot at all times (31 of 60)

Wiring diagram hot at all times for Ford Explorer IV (2005-2010)

Get access

ADJUSTABLE PEDAL MOTOR (ON PEDAL ASSEMBLY, LEFT OF BRAKE PEDAL) ADJUSTABLE PEDAL SWITCH BACK BLK WIRE BLU WIRE BRN WIRE FRONT FUSE 1 HOT AT ALL TIMES ORG/ WIRE RED WIRE SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) VIO WIRE WHT WIRE

Go to component: -> Adjustable pedal circuit -> HOT AT ALL TIMES

Wiring diagram hot at all times (32 of 60)

Wiring diagram hot at all times for Ford Explorer IV (2005-2010)

Get access

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLU WIRE BRN WIRE DRIVER SEAT LUMBAR COMPRESSOR MOTOR (IN DRIVER'S SEAT BACK) DRIVER SEAT RECLINER MOTOR (RIGHT SIDE OF DRIVER'S SEAT BACK) ENTIRE SEAT FORWARD/REARWARD FRONT OF SEAT FUSE 14 GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT POWER SEAT SWITCH LUMBAR OF SEAT REAR OF SEAT RECLINE OF SEAT RED WIRE UP/DOWN FRONT UP/DOWN REAR LEFT POWER SEAT MOTOR ASSEMBLY (UNDER DRIVER'S SEAT) VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Driver power seat circuit, with 10-way power seat -> HOT AT ALL TIMES

Wiring diagram hot at all times (33 of 60)

Wiring diagram hot at all times for Ford Explorer IV (2005-2010)

Get access

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLU WIRE BRN WIRE ENTIRE SEAT FORWARD/REARWARD FRONT OF SEAT FUSE 14 GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT POWER SEAT MOTOR ASSEMBLY (UNDER DRIVER'S SEAT) LEFT POWER SEAT SWITCH REAR OF SEAT RED WIRE UP/DOWN FRONT UP/DOWN REAR VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Driver power seat circuit, with 6-way power seat -> HOT AT ALL TIMES

Wiring diagram hot at all times (34 of 60)

Wiring diagram hot at all times for Ford Explorer IV (2005-2010)

Get access

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BRN WIRE DEFOGGER SYSTEM DR IND EXPLORER, MOUNTAINEER FHWS ON IND FHWS SWITCH FUSE GRN WIRE GRY WIRE HEATED SEAT/ WINDSHIELD SWITCH HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED LEFT FRONT SEAT BACK HEATER (IN DRIVER SEAT BACK) LEFT FRONT SEAT CUSHION HEATER (IN DRIVER SEAT) LEFT HEATED SEAT RELAY LOGIC ORG/ WIRE PS IND RED WIRE RIGHT FRONT SEAT BACK HEATER (IN FRONT PASSENGER'S SEAT BACK) RIGHT FRONT SEAT CUSHION HEATER (UNDER FRONT PASSENGER'S SEAT) RIGHT HEATED SEAT RELAY SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) SW ILLUM IND VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Heated seats circuit -> HOT AT ALL TIMES

Wiring diagram hot at all times (35 of 60)

Wiring diagram hot at all times for Ford Explorer IV (2005-2010)

Get access

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLK/GRN WIRE BLU WIRE ENTIRE SEAT FORWARD/REARWARD FRONT OF SEAT FUSE 10 GRN WIRE GRY WIRE HOT AT ALL TIMES REAR OF SEAT RED WIRE RIGHT POWER SEAT MOTOR ASSEMBLY (UNDER FRONT PASSENGER'S SEAT) RIGHT POWER SEAT SWITCH UP/DOWN FRONT UP/DOWN REAR VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Passenger power seat circuit -> HOT AT ALL TIMES

Wiring diagram hot at all times (36 of 60)

Wiring diagram hot at all times for Ford Explorer IV (2005-2010)

Get access

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLU WIRE BRN WIRE DEFOGGER INTERIOR SYSTEM LIGHTS SYSTEM DEFOGGER SYSTEM DOWN UP DRIVER SIDE EXTERIOR REAR VIEW MIRROR (FRONT OF DRIVER'S DOOR) LEFT/ RIGHT EXTERIOR REAR VIEW MIRROR SWITCH FUSE 32 GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT RIGHT MIRROR SELECT ORG/ WIRE PUDDLE LAMP UP DOWN VIO WIRE VIO/RED WIRE

Go to component: -> Power mirrors circuit, with heated mirrors -> HOT AT ALL TIMES

Wiring diagram hot at all times (37 of 60)

Wiring diagram hot at all times for Ford Explorer IV (2005-2010)

Get access

BATTERY JUNCTION BLK WIRE BLK/GRN WIRE BLU WIRE BRN WIRE DOWN UP DRIVER SIDE EXTERIOR REAR VIEW MIRROR (FRONT OF DRIVER'S DOOR) LEFT/ RIGHT EXTERIOR REAR VIEW MIRROR SWITCH FUSE 32 BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT RIGHT MIRROR SELECT ORG/ WIRE RED WIRE UP DOWN VIO WIRE

Go to component: -> Power mirrors circuit, without heated mirrors -> HOT AT ALL TIMES

Wiring diagram hot at all times (38 of 60)

Wiring diagram hot at all times for Ford Explorer IV (2005-2010)

Get access

1 2 3 4 5 6 7 8 9 10 GND ACCESSORY DELAY RELAY BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BRN WIRE CLOSE DEL ACC FUSE 1 FUSE 5 HOT AT ALL TIMES OPEN B+ RED WIRE ROOF OPENING PANEL MODULE (CENTER FRONT OF ROOF) ROOF OPENING PANEL SWITCH SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) TAN WIRE VIO WIRE VIO/BRN WIRE WHT WIRE YEL WIRE YEL/ORG WIRE

Go to component: -> Power top/sunroof circuit, with medium overhead console -> HOT AT ALL TIMES

Wiring diagram hot at all times (39 of 60)

Wiring diagram hot at all times for Ford Explorer IV (2005-2010)

Get access

ACCESSORY DELAY RELAY BLK WIRE BRN WIRE CLOSE FUSE 1 FUSE 5 GND SW COMMON DEL ACC HOT AT ALL TIMES OPEN B+ ORG/ WIRE RED WIRE ROOF OPENING PANEL MODULE (CENTER FRONT OF ROOF) ROOF OPENING PANEL SWITCH SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) VIO WIRE VIO/BRN WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/ORG WIRE

Go to component: -> Power top/sunroof circuit, without medium overhead console -> HOT AT ALL TIMES

Wiring diagram hot at all times (40 of 60)

Wiring diagram hot at all times for Ford Explorer IV (2005-2010)

Get access

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLU WIRE BRN WIRE FUSE 12 FUSE 5 GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT THIRD ROW FOLDING SEAT MOTOR (BEHIND LEFT SIDE OF THIRD ROW SEAT) LEFT THIRD ROW FOLDING SEAT RELAY (LEFT REAR CORNER OF VEHICLE) LEFT THIRD ROW FOLDING SEAT SWITCH LSD ORG/ WIRE RED WIRE RIGHT THIRD ROW FOLDING SEAT MOTOR (RIGHT REAR OF VEHICLE INTERIOR) RIGHT THIRD ROW FOLDING SEAT RELAY RIGHT THIRD ROW FOLDING SEAT SWITCH SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Third row folding seat circuit -> HOT AT ALL TIMES
