Ford Explorer IV (2005-2010) heated windshield switch Wiring diagram
This page shows the only wiring diagram for the component.heated windshield switch, which is found in the car Ford Explorer IV (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heated windshield switch (1 of 1)
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
AUDIO CONTROL MODULE (ACM)
AUTO- DIMMING INTERIOR MIRROR UNIT
BATTERY FRONT CHARGE WIPER TRAILER RELAY TOW RELAY
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CONTROL MODULE
DIGITAL TRANSMISSION RANGE (DTR) SENSOR (4.0L)
ELECTRONIC PARKING COMPASS AID MODULE (PAM)
FOUR WHEEL DRIVE SWITCH
FROM FUSE 17 SMART JUNCTION BOX (SJB) (DIAGRAM 4 OF 6)
FROM FUSE 22 SMART JUNCTION BOX (SJB) (DIAGRAM 3 OF 6)
FROM RUN START/RELAY SMART JUNCTION FUSE 9 BOX (SJB) (DIAGRAM 4 OF 5)
FUEL PUMP DIODE
FUEL PUMP RELAY
FUSE 10
FUSE 11
FUSE 12
FUSE 18
FUSE 19
GRN WIRE
GRY WIRE
HEATED SEAT/ WINDSHIELD SWITCH
HEATED WINDSHIELD SWITCH
HSD RIGHT FRONT TURN
LEFT HEATED SEAT RELAY
LOGIC
ORG/ WIRE
REAR WIPER MODULE
RED WIRE
RIGHT FRONT PARK/TURN LAMP
RIGHT HEATED SEAT RELAY
RIGHT REAR PARK/STOP TURN LAMP
RIGHT REAR STOP/ TURN
RUN/ACC
SENSE
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
SMR/ SMCS
START DIODE
TO IGNITION SWITCH (DIAGRAM 5 OF 6)
TO IGNITION SWITCH (DIAGRAM 6 OF 6)
TO SPLICE
TRACTION CONTROL SWITCH
TRANSMISSION CONTROL POWERTRAIN MODULE CONTROL MODULE (TCM) (PCM) (4.6L)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Power distribution circuit (5 of 6) -> HEATED WINDSHIELD SWITCH
