Ford Explorer IV (2005-2010) gry Wiring diagrams

ACC/DELAY RELAY BLK WIRE BLU/GRY WIRE BLU/ORG WIRE BRN WIRE BRN/GRN WIRE BRN/YEL WIRE CIRCUIT BREAKER 1 CONTROL DRIVER SIDE FRONT POWER WINDOW MOTOR (IN CENTER OF LEFT FRONT DOOR) ELECT FRONT GRN/ORG WIRE GRN/VIO WIRE GRY WIRE GRY/VIO WIRE LEFT REAR LEFT REAR POWER WINDOW MOTOR (IN CENTER OF LEFT REAR DOOR) LEFT REAR WINDOW ADJUST SWITCH LOCKOUT MASTER WINDOW ADJUST SWITCH ONE SHOT PASSENGER SIDE FRONT POWER WINDOW MOTOR (IN CENTER OF RIGHT FRONT DOOR) PASSENGER SIDE WINDOW ADJUST SWITCH RED WIRE RIGHT RIGHT REAR RIGHT REAR POWER WINDOW MOTOR (IN CENTER OF RIGHT REAR DOOR) RIGHT REAR WINDOW ADJUST SWITCH SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) VIO WIRE VIO/BLK WIRE VIO/WHT WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/GRN WIRE YEL/VIO WIRE

1 2 3 4 5 6 7 8 SW+ SW- SHIELD ENABLE/CLIP DETECT 4 5 9 MIC + MIC - SHIELD ANTENNA AUDIO CONTROL MODULE (ACM) AUDIO JACK (W/ AUDIOPHILE) (IN CENTER CONSOLE) AUTO-DIMMING INTERIOR MIRROR UNIT (W/ MICROPHONE) B+ RUN/ACC 2 3 BLK/BLU WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DETECT FUSE 11 FUSE 12 FUSE 3 GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT IN RUN OR ACC HOT IN START L FRONT SPKR + L REAR SPKR + R REAR SPKR + R FRONT SPKR + R FRONT SPKR - GND L FRONT SPKR - L REAR SPKR - R REAR SPKR - 22 23 LEFT LEFT IN + LEFT IN - SHIELD NCA WIRE RIGHT RIGHT START IN - MS CAN + MS CAN - SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) SW+ VIO WIRE VIO/GRN WIRE VIO/ORG WIRE VIO/RED WIRE VOICE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/GRN WIRE

ANT AUDIO CONTROL SWITCH BATT DRAIN L- OUT R- OUT BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK/BLU WIRE BLU WIRE BLU/BRN WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CLOCKSPRING (AT TOP OF STEERING COLUMN) COMPUTER DATA LINES SYSTEM FUSE 22 FUSE 41 GRN WIRE GRN/ORG WIRE GRN/YEL WIRE GRY WIRE GRY/ORG WIRE HOT AT ALL TIMES L+ OUT R+ OUT MS CAN- LEFT FRONT SPEAKER LEFT REAR SPEAKER MEDIA MS CAN + NCA WIRE ORG/GRN WIRE RED WIRE RED/WHT WIRE RIGHT FRONT SPEAKER RIGHT REAR SPEAKER SATELLITE DIGITAL AUDIO RECEIVER SYSTEM (SDARS) MODULE (BEHIND RIGHT KICK PANEL) SATELLITE RADIO ANTENNA SEEK SHIELD TWISTED PAIR WIRES VIO WIRE VIO/BRN WIRE VIO/ORG WIRE VOICE VOL (-) WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE

4 5 9 MIC + MIC - SHIELD ACCESSORY PROTOCOL INTERFACE MODULE (APIM) AUDIO CONTROL SWITCH AUDIO JACK (IN CENTER CONSOLE) AUTO-DIMMING INTERIOR MIRROR UNIT (W/ MICROPHONE) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLK/BLU WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN/WHT WIRE CLOCKSPRING (AT TOP OF STEERING COLUMN) COMPUTER DATA LINES SYSTEM DRAIN OUT L - OUT R - FUSE 41 GRN WIRE GRN/ORG WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES HS CAN + HS CAN - MEDIA MIC + MIC - MONO + MONO - MIC + MIC - MS CAN - MS CAN + NCA WIRE ORG/ WIRE OUT L + OUT R + PHONE RED WIRE RED/WHT WIRE SATELLITE DIGITAL AUDIO RECEIVER SYSTEM (SDARS) MODULE (BEHIND RIGHT KICK PANEL) SEEK SHIELD SHIELD SHIELD STEREO R + STEREO R - STEREO L + STEREO L - TWISTED PAIR WIRES USB USB PORT VBATT VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/ORG WIRE VOICE VOL (-) W/ SATELLITE RADIO, W/O REAR ENTERTAINMENT MODULE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/GRN WIRE

11 12 MIC + MIC - 12 11 21 8 R FRONT SPKR - R FRONT SPKR + L FRONT SPKR - L FRONT SPKR + 22 9 23 10 L REAR SPKR - L REAR SPKR + R REAR SPKR - R REAR SPKR + 3 4 2 1 SHIELD DETECT SW + SW - 4 5 MONO + MONO - 9 10 1 2 STEREO R + STEREO R - STEREO L + STEREO L - AUDIO CONTROL MODULE (ACM) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK/BLU WIRE BLU WIRE BLU/BRN WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE DETECT FUSE 22 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT SPEAKER LEFT REAR SPEAKER NCA WIRE RIGHT FRONT SPEAKER RIGHT REAR SPEAKER SW+ TWISTED PAIR WIRES VIO WIRE VIO/GRN WIRE VIO/RED WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 GND 27 28 29 30 31 32 LR SPKR + LR SPKR - LR SPKR - LR SPKR + AUDIO CONTROL SWITCH BATTERY JUNCTION BOX (BJB) BLK/BLU WIRE BLU WIRE BLU/BRN WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE CLOCKSPRING COMPUTER DATA LINES SYSTEM FUSE 41 GRN WIRE GRN/ORG WIRE GRY WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT REAR SPEAKER MEDIA NCA WIRE ORG/ WIRE OUT L + OUT R + PHONE R+ OUT R- OUT REAR ENTERTAINMENT MODULE (RETM) RED WIRE RED/WHT WIRE RIGHT REAR SPEAKER SATELLITE DIGITAL AUDIO RECEIVER SYSTEM (SDARS) MODULE SEEK SHIELD STEREO R - STEREO R + TWISTED PAIR WIRES VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/ORG WIRE VOICE VOL (-) W/ SATELLITE RECEIVER W/O SATELLITE RECEIVER WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE YEL/ORG WIRE YEL/VIO WIRE

BATTERY JUNCTION BOX (BJB) BLK/BLU WIRE BLU WIRE BLU/BRN WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE DETECT FUSE 22 GRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT REAR SPEAKER NCA WIRE RED WIRE RIGHT REAR SPEAKER SUBWOOFER AMPLIFIER (W/ AUDIOPHILE) SW+ TWISTED PAIR WIRES VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/ORG WIRE VIO/RED WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE

4 5 9 MIC + MIC - ACCESSORY PROTOCOL INTERFACE MODULE (APIM) AUDIO CONTROL MODULE (ACM) AUDIO JACK AUTO-DIMMING INTERIOR MIRROR UNIT (W/ MICROPHONE) BLK WIRE BLK/BLU WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DETECT GRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/YEL WIRE HS CAN + HS CAN - L REAR SPKR - LR SPKR MIC + MIC - MIC - MONO + MONO - MIC + MIC - MONO - MS CAN - MS CAN + NCA WIRE R REAR SPKR - RED WIRE RR SPRK - SHIELD SHIELD SHIELD STEREO 2 L + STEREO 2 L - STEREO 2 R + STEREO 2 R - SHIELD STEREO L+ STEREO R+ SW+ USB USB PORT VBATT VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/ORG WIRE VIO/RED WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/VIO WIRE

BLK WIRE BLK/VIO WIRE BLU WIRE BLU/GRY WIRE BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL) BRAKE SHIFT INTERLOCK (UNDER CENTER FLOOR CONSOLE) BREAKOUT (LEFT FRONT CORNER OF ENGINE COMPT) BRN WIRE BRN/GRN WIRE CAN (+) COMPUTER DATA LINES SYSTEM ENGINE FOUR-WHEEL DRIVE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) FUSE 20 FUSE 22 FUSE 8 GRN WIRE GRY WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED IGNITION SWITCH INSTRUMENT CLUSTER (IC) KEY IN IGNITION KEY IN SW LOCK MS MS CAN CAN NEUTRAL SWITCH OD CANCEL ORG/ WIRE OVER DRIVE SWITCH PARK DETECTION SWITCH POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE RED WIRE SENSE SHIFT LOCK SOLENOID SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) VIO WIRE WHT WIRE WHT/BLU WIRE YEL WIRE

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLU WIRE BRN WIRE FUSE 12 FUSE 5 GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT THIRD ROW FOLDING SEAT MOTOR (BEHIND LEFT SIDE OF THIRD ROW SEAT) LEFT THIRD ROW FOLDING SEAT RELAY (LEFT REAR CORNER OF VEHICLE) LEFT THIRD ROW FOLDING SEAT SWITCH LSD ORG/ WIRE RED WIRE RIGHT THIRD ROW FOLDING SEAT MOTOR (RIGHT REAR OF VEHICLE INTERIOR) RIGHT THIRD ROW FOLDING SEAT RELAY RIGHT THIRD ROW FOLDING SEAT SWITCH SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) VIO WIRE WHT WIRE YEL WIRE
