Ford Explorer IV (2005-2010) gnd sw common del acc Wiring diagram
This page shows the only wiring diagram for the component.gnd sw common del acc, which is found in the car Ford Explorer IV (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd sw common del acc (1 of 1)
ACCESSORY DELAY RELAY
BLK WIRE
BRN WIRE
CLOSE
FUSE 1
FUSE 5
GND SW COMMON DEL ACC
HOT AT ALL TIMES
OPEN B+
ORG/ WIRE
RED WIRE
ROOF OPENING PANEL MODULE (CENTER FRONT OF ROOF)
ROOF OPENING PANEL SWITCH
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
VIO WIRE
VIO/BRN WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component: -> Power top/sunroof circuit, without medium overhead console -> GND SW COMMON DEL ACC
