Ford Explorer IV (2005-2010) except sport trac Wiring diagrams

This page contains all the electrical diagrams for the component. except sport trac, in which he is found in the car Ford Explorer IV (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram except sport trac (1 of 3)

Wiring diagram except sport trac for Ford Explorer IV (2005-2010)

Get access

AUTO- DIMMING INTERIOR MIRROR UNIT BLK WIRE BRN/BLU WIRE EXCEPT SPORT TRAC FUSE GRY/ORG WIRE HOT W/ REVERSE LAMP RELAY ENERGIZED HOT W/ RUN/START RELAY ENERGIZED IGN REV SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) SPORT TRAC

Go to component: -> Electrochromic mirror circuit, without microphone -> EXCEPT SPORT TRAC

Wiring diagram except sport trac (2 of 3)

Wiring diagram except sport trac for Ford Explorer IV (2005-2010)

Get access

A/C CLUTCH RELAY BATTERY JUNCTION BLK WIRE BLK/GRN WIRE BLK/ORG WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BRN/WHT WIRE BRN/YEL WIRE CDA CDB CDC ECT EVAP EXCEPT SPORT TRAC FC-V FP PWR FPC FPM FPM RTN FRT FUEL PUMP DRIVER MODULE FUEL PUMP MOTOR (UNDER RIGHT SIDE OF VEHICLE) FUEL PUMP RELAY FUEL TANK LEVEL SENSOR (UNDER RIGHT SIDE OF VEHICLE) FUSE 4 FUSE 40 FUSE 38 FUSE 42 FUSE 43 FUSE 39 FUSE 44 FUSE 7 GRN WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/VIO WIRE HEATED POSITIVE CRANKCASE HOT AT ALL TIMES IGNITION TRANSFORMER CAPACITOR (AT TOP LEFT OF ENGINE) INERTIA FUEL SHUTOFF (IFS) SWITCH (BEHIND RIGHT KICK PANEL) INSTRUMENT CLUSTER SYSTEM MD GND NCA WIRE PCM POWER RELAY PCV HC PNK/BLK WIRE POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE ENGINE) SPORT TRAC VBPWR VIO WIRE VIO/GRN WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE YEL/WHT WIRE

Go to component: -> Wiring diagram engine performance 4.0l (2 of 5) -> EXCEPT SPORT TRAC

Wiring diagram except sport trac (3 of 3)

Wiring diagram except sport trac for Ford Explorer IV (2005-2010)

Get access

A/C CLUTCH RELAY BATTERY JUNCTION BLK WIRE BLK/GRN WIRE BLK/ORG WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/ORG WIRE BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BRN/WHT WIRE BRN/YEL WIRE CDA CDB CDC CDD CDE CDF CDG CDH EVAP EXCEPT SPORT TRAC FC-V FP PWR FPC FPM FPM RTN FRT FUEL PUMP DRIVER MODULE FUEL PUMP MOTOR (UNDER RIGHT SIDE OF VEHICLE) FUEL PUMP RELAY FUEL TANK LEVEL SENSOR (UNDER RIGHT SIDE OF VEHICLE) FUSE 39 FUSE 43 FUSE 40 FUSE 4 FUSE 42 FUSE 44 FUSE 7 GRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/VIO WIRE HOT AT ALL TIMES INERTIA FUEL SHUTOFF (IFS) SWITCH (BEHIND RIGHT KICK PANEL) INSTRUMENT CLUSTER SYSTEM MD GND NCA WIRE PCM POWER RELAY PNK/BLK WIRE POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE ENGINE) SPORT TRAC VBPWR VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/ORG WIRE VIO/WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE YEL/WHT WIRE

Go to component: -> Wiring diagram engine performance 4.6l (2 of 5) -> EXCEPT SPORT TRAC
