Ford Explorer IV (2005-2010) engine coolant temperature sensor (ect) (4.0l) (top center front of engine) wiring diagram
This page shows the only wiring diagram for the component.engine coolant temperature sensor (ect) (4.0l) (top center front of engine), which is found in the car Ford Explorer IV (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
engine coolant temperature sensor (ect) (4.0l) (top center front of engine) wiring diagram (1 of 1)
20 24 7 58 18 VBPWR FSS FC V SIGRTNE ECT
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK/GRN WIRE
BLK/YEL WIRE
BLU/BLK WIRE
ELECTRONIC FAN CLUTCH (CENTER FRONT OF ENGINE)
ENGINE COOLANT TEMPERATURE SENSOR (ECT) (4.0L) (TOP CENTER FRONT OF ENGINE)
FUSE 40
GND 2 3 4 6 VPWR VBPWR FSS FC V
GRN/ WHT WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT W/ PCM RELAY ENERGIZED
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE)
VIO/GRN WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
