Ford Explorer IV (2005-2010) driver side front door ajar switch (at rear of left front Wiring diagrams

This page contains all the electrical diagrams for the component. driver side front door ajar switch (at rear of left front, in which he is found in the car Ford Explorer IV (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram driver side front door ajar switch (at rear of left front (1 of 2)

Wiring diagram driver side front door ajar switch (at rear of left front for Ford Explorer IV (2005-2010)

Get access

1/2 3/4 5/6 7/8 9/0 ALL LOCK RELAY ALL UNLOCK RELAY BLK WIRE BLU WIRE BLU/GRN WIRE BRN WIRE CNTRL DOOR DRIVER SIDE DOOR LOCK SWITCH DRIVER SIDE FRONT DOOR AJAR SWITCH (AT REAR OF LEFT FRONT DRIVER SIDE REAR DOOR AJAR SWITCH (AT REAR OF LEFT REAR DOOR) DRIVER UNLOCK RELAY FUSE 6 GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/YEL WIRE HOT AT ALL TIMES HSD KEY PAD SWITCH ASSEMBLY LEFT REAR DOOR LOCK ACTUATOR (AT REAR OF LEFT REAR DOOR) LOCK OFF ON OFF ORG/ WIRE PASSENGER SIDE DOOR LOCK ACTUATOR (AT REAR OF RIGHT FRONT DOOR) PASSENGER SIDE DOOR LOCK SWITCH PASSENGER SIDE FRONT DOOR AJAR SWITCH (AT REAR OF RIGHT FRONT DOOR) PASSENGER SIDE REAR DOOR AJAR SWITCH (AT REAR OF RIGHT REAR DOOR) RIGHT REAR DOOR LOCK ACTUATOR (AT REAR OF RIGHT REAR DOOR) SENSE SENSE SENSE SENSE SENSE SENSE SENSE SENSE SENSE SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) UNLOCK UNLOCK LOCK VIO WIRE VIO/GRN WIRE VIO/GRY WIRE WHT WIRE WHT/GRN WIRE YEL WIRE YEL/GRN WIRE

Go to component: -> Forced entry circuit -> DRIVER SIDE FRONT DOOR AJAR SWITCH (AT REAR OF LEFT FRONT

Wiring diagram driver side front door ajar switch (at rear of left front (2 of 2)

Wiring diagram driver side front door ajar switch (at rear of left front for Ford Explorer IV (2005-2010)

Get access

1/2 3/4 5/6 7/8 9/0 ALL LOCK RELAY ALL UNLOCK RELAY BLK WIRE BLU WIRE BLU/GRN WIRE BRN WIRE CNTRL DOOR DRIVER SIDE DOOR LOCK SWITCH DRIVER SIDE FRONT DOOR AJAR SWITCH (AT REAR OF LEFT FRONT DRIVER SIDE REAR DOOR AJAR SWITCH (AT REAR OF LEFT REAR DOOR) DRIVER UNLOCK RELAY FUSE 6 GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/YEL WIRE HOT AT ALL TIMES HSD KEY PAD SWITCH ASSEMBLY LEFT REAR DOOR LOCK ACTUATOR (AT REAR OF LEFT REAR DOOR) LOCK OFF ON OFF ORG/ WIRE PASSENGER SIDE DOOR LOCK ACTUATOR (AT REAR OF RIGHT FRONT DOOR) PASSENGER SIDE DOOR LOCK SWITCH PASSENGER SIDE FRONT DOOR AJAR SWITCH (AT REAR OF RIGHT FRONT DOOR) PASSENGER SIDE REAR DOOR AJAR SWITCH (AT REAR OF RIGHT REAR DOOR) RIGHT REAR DOOR LOCK ACTUATOR (AT REAR OF RIGHT REAR DOOR) SENSE SENSE SENSE SENSE SENSE SENSE SENSE SENSE SENSE SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) UNLOCK UNLOCK LOCK VIO WIRE VIO/GRN WIRE VIO/GRY WIRE WHT WIRE WHT/GRN WIRE YEL WIRE YEL/GRN WIRE

Go to component: -> Power door locks circuit -> DRIVER SIDE FRONT DOOR AJAR SWITCH (AT REAR OF LEFT FRONT
