Ford Explorer IV (2005-2010) defogger system Wiring diagrams
This page contains all the electrical diagrams for the component. defogger system, in which he is found in the car Ford Explorer IV (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
defogger system wiring diagram (1 of 2)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
DEFOGGER SYSTEM
DR IND
EXPLORER, MOUNTAINEER
FHWS ON IND
FHWS SWITCH
FUSE
GRN WIRE
GRY WIRE
HEATED SEAT/ WINDSHIELD SWITCH
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
LEFT FRONT SEAT BACK HEATER (IN DRIVER SEAT BACK)
LEFT FRONT SEAT CUSHION HEATER (IN DRIVER SEAT)
LEFT HEATED SEAT RELAY
LOGIC
ORG/ WIRE
PS IND
RED WIRE
RIGHT FRONT SEAT BACK HEATER (IN FRONT PASSENGER'S SEAT BACK)
RIGHT FRONT SEAT CUSHION HEATER (UNDER FRONT PASSENGER'S SEAT)
RIGHT HEATED SEAT RELAY
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
SW ILLUM IND
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Heated seats circuit -> DEFOGGER SYSTEM
defogger system wiring diagram (2 of 2)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BLU WIRE
BRN WIRE
DEFOGGER INTERIOR SYSTEM LIGHTS SYSTEM
DEFOGGER SYSTEM
DOWN UP
DRIVER SIDE EXTERIOR REAR VIEW MIRROR (FRONT OF DRIVER'S DOOR) LEFT/ RIGHT
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE 32
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT RIGHT
MIRROR SELECT
ORG/ WIRE
PUDDLE LAMP
UP DOWN
VIO WIRE
VIO/RED WIRE
Go to component -> Power mirrors circuit, with heated mirrors -> DEFOGGER SYSTEM
