Ford Explorer IV (2005-2010) control ms ms can can Wiring diagram
This page shows the only wiring diagram for the component.control ms ms can can, which is found in the car Ford Explorer IV (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram control ms ms can can (1 of 1)
11 23 HS CAN + HS CAN -
35 36 VPWR VPWR
8 7 5 4 HS CAN - HS CAN + MS CAN - MS CAN +
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL MS MS CAN CAN
FUSE 15
FUSE 39
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
INSTRUMENT CLUSTER (IC)
LEFT REVERSING LAMP RIGHT REVERSING LAMP
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE)
REVERSE LAMP RELAY
SIGRTNT
SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH)
TRANSFER CASE ASSEMBLY (5 SPEED) (LEFT REAR OF TRANSFER CASE)
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component: -> Backup lamps circuit -> CONTROL MS MS CAN CAN
