Ford Explorer IV (2005-2010) 29 37 od cancel power hold Wiring diagram

29 37 OD CANCEL POWER HOLD 34 45 44 PCC CTRL SHIFT SOL D CTRL SHIFT SOL C CTRL 46 43 42 TCC SOL CTRL SHIFT SOL B CTRL SHIFT SOL A CTRL BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLU/BRN WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRAKE SHIFT INTERLOCK (UNDER CENTER FLOOR CONSOLE) BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE ENGINE CONTROLS SYSTEM FUSE 20 FUSE 38 FUSE 42 FUSE 7 GRN WIRE GRN/BRN WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HEATED HEATED OXYGEN SENSOR OXYGEN SENSOR HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED HTR 12 CTRL TSS SENS SIG OSS SENS SIG ISS SENS SIG HTR 22 CTRL INTERMEDIATE SHAFT SPEED (ISS) SENSOR (TOP LEFT SIDE OF AUTOMATIC TRANSMISSION) OUTPUT SHAFT SPEED (OSS) SENSOR (LEFT REAR OF AUTOMATIC TRANSMISSION) OVER DRIVE SWITCH PCA CTRL PCA CTRL SIGRTN TFT PCB CTRL TFT SENS INPUT PCM POWER RELAY POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE ENGINE) SIG RTN SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) TCC SOL CTRL SHIFT SOL B CTRL SHIFT SOL A CTRL TRANSMISSION ASSEMBLY TURBINE SHAFT SPEED (TSS) SENSOR (TOP LEFT SIDE OF AUTOMATIC TRANSMISSION) VIO WIRE VIO/GRY WIRE VIO/WHT WIRE WHT WIRE WHT/ORG WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE
