Ford Explorer IV (2005-2010) 12 13 7 39 hs can + hs can - fluid sw ret fluid lvl sw Wiring diagram

12 13 7 39 HS CAN + HS CAN - FLUID SW RET FLUID LVL SW ANTI-LOCK BRAKE SYSTEM (ABS) MODULE (LEFT FRONT OF ENGINE COMPT) AUTO- LP AUTOLP ON BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/VIO WIRE BLU/GRY WIRE BLU/ORG WIRE BRAKE FLUID LEVEL SWITCH BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER SAFETY BELT BUCKLE SWITCH (UNDER DRIVER SEAT) DRIVER SIDE FRONT DOOR AJAR SWITCH (AT REAR OF LEFT FRONT DOOR) DRIVER SIDE REAR DOOR AJAR SWITCH (AT REAR OF LEFT REAR DOOR) DRV BUCKLE SW FOG LP FUSE 17 FUSE 8 (BEHIND LEFT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HDLP OFF HDLP ON HOT AT ALL TIMES SMART JUNCTION BOX (SJB) HOT W/ RUN/ START RELAY ENERGIZED HS CAN+ IGNITION SWITCH INSTRUMENT CLUSTER (IC) KEY IN KEY-IN IGNITION SWITCH LEFT TURN LH TURN LIFTGATE AJAR SWITCH (LOWER CENTER OF LIFTGATE) LIFTGATE GLASS AJAR SWITCH MAIN LIGHT SWITCH MS CAN + MULTI- FUNCTION SWITCH NCA WIRE PARK BRAKE SWITCH (BEHIND TOP OF LEFT KICK PANEL) PARK LP PARK LP ON PARKING BRAKE SWITCH (BEHIND TOP OF LEFT KICK PANEL) PASSENGER SIDE FRONT DOOR AJAR SWITCH (AT REAR OF RIGHT FRONT DOOR) PASSENGER SIDE REAR DOOR AJAR SWITCH (AT REAR OF RIGHT REAR DOOR) RESTRAINTS CONTROL MODULE (RCM) (BELOW CENT FLOOR CONSOLE) RH TURN RIGHT TURN RUN/START SENSE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/VIO WIRE WIPER/ WASHER SYSTEM YEL WIRE YEL/GRY WIRE YEL/ORG WIRE
