Ford Explorer IV (2005-2010) 1. full left 2. lane change 3. neutral 4. lane change 5. full right Wiring diagram

This page shows the only wiring diagram for the component.1. full left 2. lane change 3. neutral 4. lane change 5. full right, which is found in the car Ford Explorer IV (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 1. full left 2. lane change 3. neutral 4. lane change 5. full right (1 of 1)

Wiring diagram 1. full left 2. lane change 3. neutral 4. lane change 5. full right for Ford Explorer IV (2005-2010)

Get access

1. AUTO 2. OFF 3. PARK 4. LOW 1. FULL LEFT 2. LANE CHANGE 3. NEUTRAL 4. LANE CHANGE 5. FULL RIGHT BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL) BRN WIRE CARGO LAMP ASSEMBLY CONTROL FUSE 22 FUSE 26 FUSE 7 GRN WIRE GRY WIRE HAZARD HOT AT ALL TIMES HSD LEFT FRONT PARK/ TURN LAMP LEFT FRONT SIDE LAMP LEFT FRONT TURN LEFT LICENSE PLATE LAMP LEFT REAR PARK/ STOP/ TURN LAMP RIGHT LICENSE PLATE LAMP LEFT REAR TURN/ STOP MAIN LIGHT SWITCH MULTI- FUNCTION SWITCH NCA WIRE ORG/ WIRE PARK LAMP RELAY RED WIRE REST ON/ OFF RIGHT FRONT PARK/ TURN LAMP RIGHT FRONT SIDE LAMP RIGHT FRONT TURN RIGHT REAR PARK/ STOP/ TURN LAMP RIGHT REAR TURN/ STOP SENSE SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) STOP CARGO TURN SIGNAL VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Exterior lamps circuit -> 1. FULL LEFT 2. LANE CHANGE 3. NEUTRAL 4. LANE CHANGE 5. FULL RIGHT
