Ford Explorer IV (2005-2010) 1 2 3 4 trailer tow connector Wiring diagram

This page shows the only wiring diagram for the component.1 2 3 4 trailer tow connector, which is found in the car Ford Explorer IV (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 1 2 3 4 trailer tow connector (1 of 1)

Wiring diagram 1 2 3 4 trailer tow connector for Ford Explorer IV (2005-2010)

Get access

1 2 3 4 TRAILER TOW CONNECTOR BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE CONTROL FUSE 17 FUSE 25 FUSE 7 GRN WIRE HOT AT ALL TIMES HOT AT ALL TIMES SMART JUNCTION BOX (SJB) (BEHIND LEFT SIDE OF DASH) HSD PARK LAMP RELAY RED WIRE WHT WIRE YEL WIRE

Go to component: -> Trailer tow circuit, with light duty -> 1 2 3 4 TRAILER TOW CONNECTOR
