Car Wiring Diagrams for 4wd circuit, without ivd for Ford Explorer III (2001-2006)

ABS CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) BATTERY JUNCTION (BJB) BOX (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/LT BLU WIRE BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL) BRN WIRE BRN/WHT WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) DATA LINK CONNECTOR DIGITAL TRANSMISSION RANGE SENSOR (LEFT SIDE OF TRANSMISSION) DK BLU WIRE ENGINE COMPARTMENT RELAY BOX (RIGHT SIDE OF ENGINE COMPT) FOUR WHEEL DRIVE SWITCH FUSE 12 FUSE 15 FUSE 18 FUSE 24 FUSE 25 FUSE 8 FUSE 17 GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN OR START ILLUM J/C 1 (IN BATTERY JUNCTION BOX) LT BLU/BLK WIRE LT GRN WIRE MAGNETIC CLUTCH COIL NEUTRAL TOW INDICATOR OFF ORG/ WIRE ORG/WHT WIRE POSITION IND POWERTRAIN CONTROL MODULE (RIGHT SIDE ENGINE BULKHEAD) RED WIRE RED/BLK WIRE RED/LT GRN WIRE RED/WHT WIRE TAN WIRE TAN/BLK WIRE TRANSFER CASE ASSEMBLY (ON LEFT SIDE OF TRANSFER CASE) TRANSFER CASE HIGH TO LOW RELAY TRANSFER CASE LOW TO HIGH RELAY VIO WIRE VIO/ORG WIRE VIO/YEL WIRE WHT WIRE YEL WIRE YEL/WHT WIRE
