Car Wiring Diagrams for Charging circuit for Ford Explorer III (2001-2006)

BATTERY (AT LEFT FRONT OF ENGINE COMPT) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLK/ORG WIRE BRN WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) CHARGE INDICATOR COMPT) FUSE 14 FUSIBLE LINK A FUSIBLE LINK B (12 GA- FUSIBLE LINK C (18 GA- GENERATOR (AT RIGHT FRONT OF ENGINE COMPT) GRY WIRE HOT IN START OR RUN INSTRUMENT CLUSTER LT GRN WIRE MICRO- PROCESSOR RED WIRE RED/YEL WIRE STARTER MOTOR (ON LEFT REAR OF ENGINE) YEL/WHT WIRE
