Radio circuit, without audiophile system for Ford Explorer III (2001-2006)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 ILLUM RETURN GROUND FUSED IGNITION AIR BAG CONTACT AIR BAG SLIDING CONTACT (AT TOP OF STEERING COLUMN) AIR CONDITIONING SYSTEM ANTENNA AUDIO UNIT AUDIO/ CLIMATE CONTROL SWITCH BLK WIRE BLK/LT BLU WIRE BLK/ORG WIRE BLK/PNK WIRE BRN WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) CIRCUIT BREAKER PTC 1 CRUISE CONTROL SYSTEM DK GRN WIRE DK GRN/ORG WIRE FAN DOWN FAN UP FUSE 28 FUSE 3 GRN WIRE GRY WIRE GRY/BLK WIRE GRY/LT BLU WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN START HOT WITH ACC DELAY RELAY ENERGIZED LEFT FRONT SPEAKER LEFT REAR SPEAKER LT BLU WIRE LT BLU/WHT WIRE MEDIA NCA WIRE NEXT ORG/ WIRE ORG/LT GRN WIRE ORG/RED WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (AT RIGHT SIDE ENGINE BULKHEAD) RED WIRE RED/BLK WIRE RIGHT FRONT SPEAKER RIGHT REAR SPEAKER TAN/YEL WIRE TEMP DOWN TEMP UP TWISTED PAIR VEHICLE SPEED VOL DOWN VOL UP VSS WHT WIRE WHT/LT GRN WIRE WHT/YEL WIRE WINDSHIELD WIPER MOTOR (AT LEFT REAR OF ENGINE COMPT) VSS YEL WIRE
