Car Wiring Diagrams for Power windows circuit for Ford Explorer III (2001-2006)

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BRN WIRE CIRCUIT CLOSE DN UP DRIVER SIDE FRONT POWER WINDOW MOTOR (IN BOTTOM CENTER OF DRIVER DOOR) FUSE GRY WIRE HOT AT ALL TIMES ILLUM INSTRUMENT CLUSTER INTERIOR LIGHTS SYSTEM (AT LEFT KICK PANEL) LEFT REAR LEFT REAR POWER WINDOW MOTOR (IN CENTER OF LEFT REAR DOOR) LEFT REAR WINDOW ADJUST SWITCH LOCK LT BLU WIRE LT GRN WIRE MASTER WINDOW ADJUST SWITCH ONE- TOUCH DOWN ONE-TOUCH DOWN RELAY OPEN/ VENT ORG/ WIRE PASSENGER PASSENGER SIDE FRONT POWER WINDOW MOTOR (IN BOTTOM CENTER OF PASSENGER DOOR) PASSENGER SIDE WINDOW ADJUST SWITCH PNK WIRE RADIO REAR WINDOW ADJUST SWITCH REAR WINDOW MOTOR (UNDER CENTER OF REAR WINDOW) RED WIRE RIGHT REAR RIGHT REAR POWER WINDOW MOTOR (IN CENTER OF RIGHT REAR DOOR) RIGHT REAR WINDOW ADJUST SWITCH ROOF OPENING PANEL MODULE (AT FRONT CENTER OF ROOF) TAN WIRE UP DN UP DN DN VBATT VIO WIRE VPWR VREF WHT WIRE WINDOW SAFETY RELAY YEL WIRE
