Power top/sunroof circuit for Ford Explorer III (2001-2006)
Power top/sunroof circuit
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
DK BLU WIRE
DOWN/ OPEN
FUSE 10
FUSE 39
GND VBATT VREF VREF VPWR
HOT AT ALL TIMES
HOT WITH WINDOW SAFETY RELAY ENERGIZED
LT GRN WIRE
RED WIRE
ROOF OPENING PANEL MODULE (AT FRONT CENTER OF ROOF)
ROOF OPENING PANEL SWITCH
UP/ CLOSE
VIO WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/LT GRN WIRE
