Heated seats circuit for Ford Explorer III (2001-2006)
Heated seats circuit
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DK GRN WIRE
DRIVER SIDE SEAT BACK HEATER (IN DRIVER SEAT)
DRIVER SIDE SEAT CUSHION HEATER (IN DRIVER SEAT)
DRIVER SIDE SEAT HEATER SWITCH
FUSE
FUSE 15
GRY/LT BLU WIRE
GRY/YEL WIRE
HEATED SEATS RELAY (ON FLOOR, UNDER DRIVER SEAT)
HOT AT ALL TIMES
HOT IN RUN
ILLUM
INDICATOR
PASSENGER SIDE SEAT BACK HEATER (IN PASSENGER SEAT)
PASSENGER SIDE SEAT CUSHION HEATER (IN PASSENGER SEAT)
PASSENGER SIDE SEAT HEATER SWITCH
RED/BLK WIRE
VIO/LT BLU WIRE
YEL/LT BLU WIRE
