Electronic day/night mirror circuit for Ford Explorer III (2001-2006)
Electronic day/night mirror circuit
BLK WIRE
BLK/PNK WIRE
CENTRAL JUNCTION
CENTRAL SECURITY MODULE (W/ KEYLESS ENTRY) (BEHIND TOP RIGHT SIDE OF DASH)
DIGITAL TRANSMISSION RANGE (DTR) SENSOR (AT CENTER OF AUTOMATIC TRANSMISSION)
ELECTROCHROMATIC INSIDE MIRROR UNIT
FUSE 19
FUSE BOX (CJB) (BEHIND LEFT SIDE OF DASH)
HOT IN RUN
HOT IN START OR RUN
RED/YEL WIRE
REVERSE SENSE
VIO/ORG WIRE
W/ DRL
