Power door locks circuit, without keyless entry for Ford Explorer III (2001-2006)
Power door locks circuit, without keyless entry
AUXILIARY RELAY BOX 2 (UNDER LEFT SIDE OF DASH, NEAR STEERING COLUMN)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER SIDE DOOR LOCK ACTUATOR (IN REAR BOTTOM OF DRIVER DOOR)
DRIVER SIDE DOOR LOCK SWITCH
FUSE 26
HOT AT ALL TIMES
LEFT REAR DOOR LOCK ACTUATOR (IN BOTTOM
LOCK
LT GRN WIRE
LT GRN/ORG WIRE
ORG/ WIRE
PASSENGER SIDE DOOR LOCK ACTUATOR (IN BOTTOM REAR OF PASSENGER DOOR)
PASSENGER SIDE DOOR LOCK SWITCH
PNK PNK WIRE
PNK WIRE
PNK/LT GRN WIRE
PNK/ORG WIRE
PNK/YEL WIRE
RED WIRE
RIGHT REAR DOOR LOCK ACTUATOR (IN BOTTOM
UNLOCK
WHT WIRE
WHT/YEL WIRE
YEL WIRE
